Description
Type C Aluminum honeycomb wall panels are class B-15 fire resistant. The surface finish is a PVC film (150u) and low flame spread, this means that the surface will adequately restrict the spread of flames or the option can be galvanized steel.
Type C Aluminum Honeycomb Wall Panel
Type C Aluminum honeycomb wall panels are class B-15 fire resistant. The surface finish is a PVC film (150u) and low flame spread, this means that the surface will adequately restrict the spread of flames or the option can be galvanized steel.
The core material is lightweight Aluminum Honeycomb. In need for another installation method, visit our Type A aluminum honeycomb wall panels page.
The Aluminum wall panels are available in standard sizes of 550 mm width x required length with a maximum of 3500 mm. The tolerance of width is -1,0mm, height ±3 mm or thickness -1,0mm.
The table below shows the 6 variances of the type C Aluminum wall panels that are available.
| Type | CLP-P11 | CLP-L7 | CLP-L8 | CLP-L12 | CLP-L13 | CLP-L14 |
| Fire-class | B-15 | B-15 | B-15 | B-15 | B-15 | B-15 |
| Thickness (mm) | 50 | 30 | 25 | 50 | 30 | 25 |
| Weight kg/m2 | 7.2 | 6.5 | 6.2 | 13 | 12.4 | 12 |
| Surface finish | PVC film / Powder Painted + Aluminum Plate | PVC film / Powder Painted + Galvanized Steel Plate | ||||
